Cooling fan circuit, hybrid for Toyota Avalon XX40 (2012-2015)

13 26 44 CANH CANL RFC 95 96 THW BLK WIRE COMPUTER DATA LINES SYSTEM COOLING FAN ECU (ON COOLING FAN MOTOR) EFI ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE) ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FAN RELAY FUSE GRN WIRE HOT AT ALL TIMES ENGINE ROOM J/B (LEFT FAN SIDE OF FUSE ENGINE COMPT) HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT END OF DASH) PNK ETHW WIRE PNK WIRE RED WIRE VIO WIRE WHT WIRE WHT/BLK WIRE
