Toyota Avalon XX40 (2012-2015) w/o extension module Wiring diagrams

This page contains all the electrical diagrams for the component. w/o extension module, in which he is found in the car Toyota Avalon XX40 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram w/o extension module (1 of 4)

Wiring diagram w/o extension module for Toyota Avalon XX40 (2012-2015) (1 of 4)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 B+ SPD AGND AVC- BKUP LP FUSE BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY (RIGHT SIDE OF ENGINE COMPT) BRN WIRE CA+ V+ CB+ CGND COMPUTER DATA LINES SYSTEM CV+ EXCEPT HYBRID EXTENSION MODULE (IF EQUIPPED) (CENTER OF DASH) GPS ANTENNA GRN WIRE GRY WIRE HSYN INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/C LT BLU WIRE LT GRN WIRE MIC + MIC - MIC - MUTE NCA WIRE ORG/ WIRE PNK AVC+ AVC- WIRE PNK WIRE R+ R- L+ L- MUTE RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE RELAY ENERGIZED SATELLITE RADIO ANTENNA ASSEMBLY (W/ SDARS) SDARS ANTENNA SHIELD SHIELD CGND V- TELEPHONE ANTENNA ASSEMBLY (W/ SDARS) V G V-B V-R VIO WIRE VOL (-) VOL VOL VSHD VSYN VSYN HSYN AGND VSHD V-B V-G V-R W/ EXTENSION MODULE W/O EXTENSION MODULE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> 8-speaker system circuit (1 of 4) -> W/O EXTENSION MODULE

Wiring diagram w/o extension module (2 of 4)

Wiring diagram w/o extension module for Toyota Avalon XX40 (2012-2015) (2 of 4)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 B+ SPD AGND AVC- BKUP LP FUSE BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY (RIGHT SIDE OF ENGINE COMPT) BRN WIRE CB+ CGND COMPUTER DATA LINES SYSTEM CV+ EXCEPT HYBRID EXTENSION MODULE (IF EQUIPPED) (CENTER OF DASH) GPS ANTENNA GRN WIRE GRY WIRE HSYN INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/C LT BLU WIRE LT GRN WIRE MIC + MIC - MIC - MUTE NCA WIRE ORG/ WIRE PARKING BRAKE SWITCH ASSEMBLY (BASE OF PARKING BRAKE FOOT PEDAL ASSEMBLY) PKB CA+ V+ PNK AVC+ AVC- WIRE PNK WIRE R+ R- L+ L- MUTE RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE RELAY ENERGIZED SATELLITE RADIO ANTENNA ASSEMBLY (W/ SDARS) SDARS ANTENNA SHIELD SHIELD CGND V- TELEPHONE ANTENNA ASSEMBLY (W/ SDARS) V G V-B V-R VIO WIRE VOL (-) VOL VOL VSHD VSYN VSYN HSYN AGND VSHD V-B V-G V-R W/ EXTENSION MODULE W/O EXTENSION MODULE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> 9-speaker system circuit (1 of 4) -> W/O EXTENSION MODULE
