Toyota Avalon XX40 (2012-2015) tail relay Wiring diagrams
This page contains all the electrical diagrams for the component. tail relay, in which he is found in the car Toyota Avalon XX40 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tail relay (1 of 4)
+ECU
AUTO
BLK WIRE
BLU WIRE
CANADA USA
COMPUTER DATA LINES SYSTEM
DRL OFF
FUSE
GRN WIRE
GRY WIRE
HEAD
HID
HOT AT ALL TIMES
HOT W/ ACC 1 RELAY ENERGIZED
INSTRUMENT PANEL J/B (LEFT END OF DASH)
LCTY
LEFT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT ASSEMBLY
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LIGHT CONTROL SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY
MAIN BODY ECU (ATTACHED TO INSTRUMENT PANEL J/B)
OFF
ORG/ WIRE
PARKING
PNK WIRE
RCTY
RED WIRE
RELAY ENERGIZED
RIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT ASSEMBLY
RIGHT LICENSE PLATE LIGHT ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SIDE MARKER
STOP
TAIL
TAIL FUSE
TAIL RELAY
TURN
TURN SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, except hybrid (1 of 3) -> TAIL RELAY
Wiring diagram tail relay (2 of 4)
30 13 TAIL CANL CANH COMPUTER DATA LINES PNK SYSTEM WIRE
8 1 ILLB GND
A/C
ALT FUSE
ALTB TRLY
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
DC/DC FUSE
ECU FUSE
ECU-B 1 FUSE
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
EXCEPT HYBRID
FUSE
GRN WIRE
GRY WIRE
HAZARD ILL+ WARNING SIGNAL SWITCH ASSEMBLY
HID
HOT AT ALL TIMES
ILL- ASSEMBLY (W/ NAVIGATION) (CENTER OF DASH)
ILL- GND ILL+
INSTRUMENT PANEL J/B (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
LUGGAGE ILL+ DOOR OPENING SWITCH ASSEMBLY
MAIN BODY ECU (ATTACHED TO INSTRUMENT PANEL J/B)
ORG/ WIRE
PANEL FUSE
PNK WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY (W/O NAVIGATION) NAVIGATION RECEIVER
RED WIRE
RELAY ENERGIZED
ROOF CONSOLE BOX ASSEMBLY
SHIFT ILL+ POSITION INDICATOR (INDICATOR LIGHT WIRE SUB-ASSEMBLY)
TAIL RELAY
VIO WIRE
VSC OFF ILL+ SWITCH
W/ NAVIGATION
W/O NAVIGATION
W/O NAVIGATION W/ 11 SPEAKER
W/O NAVIGATION, 11 SPEAKER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> TAIL RELAY
Wiring diagram tail relay (3 of 4)
ACC 1 RELAY
ACC 2 RELAY
ANTI-LOCK BRAKES, EXTERIOR LIGHTS, TRANSMISSIONS SYSTEMS
BKUP LP FUSE
BLK WIRE
BLU WIRE
FROM CERTIFICATION ECU (DIAGRAM 3 OF 5)
FROM F/L DOOR FUSE (DIAGRAM 4 OF 5)
FUSE
FUSE (DIAGRAM 3 OF 5)
FUSE (DIAGRAM 4 OF 5)
GRN WIRE
GRY WIRE
H-LP LVL S/HTR RR FUSE
HEADLIGHTS SYSTEM
LT GRN WIRE
MAIN BODY ECU
PANEL FUSE
PNK WIRE
RED WIRE
RELAY
S/HTR, FAN F/L
S/HTR, FAN F/R FUSE
SEATS SYSTEM
TAIL FUSE
TAIL RELAY
TO ECU-ACC FUSE (DIAGRAM 4 OF 5)
TO P/OUTLET FR FUSE (DIAGRAM 4 OF 5)
VIO WIRE
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WIPER FUSE
WIPER/WASHER SYSTEM
Go to component -> Power distribution circuit, except hybrid (5 of 5) -> TAIL RELAY
Wiring diagram tail relay (4 of 4)
+ECU
ACC 1 RELAY
ACC 2 RELAY
BLK WIRE
BLU WIRE
ELECTRONIC POWER STEERING SYSTEM
FROM F/L DOOR FUSE (DIAGRAM 4 OF 5)
FROM POWER MANAGEMENT CONTROL ECU (DIAGRAM 3 OF 5)
FUSE
FUSE (DIAGRAM 4 OF 5)
FUSE FUSE
GRN WIRE
GRY WIRE
H-LP LVL S/HTR RR FUSE
HEADLIGHTS SYSTEM
LT GRN WIRE
LT PNK WIRE
MAIN BODY ECU
PANEL FUSE
PNK WIRE
RED WIRE
RELAY
S/HTR, FAN F/L
S/HTR, FAN F/R FUSE
SEATS SYSTEM
SEATS, POWER WINDOWS, NAVIGATION SYSTEMS
TAIL FUSE
TAIL RELAY
TO ECU-ACC FUSE (DIAGRAM 4 OF 5)
TO FR P/OUTLET (DIAGRAM 4 OF 5)
TO INSTRUMENT PANEL J/B (DIAGRAM 3 OF 5)
TRLY IG
VIO WIRE
WARNING SYSTEMS
WASHER FUSE
WHT WIRE
WIPER FUSE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, hybrid (5 of 5) -> TAIL RELAY
