Toyota Avalon XX40 (2012-2015) steering pad switch horn switch assembly Wiring diagram
This page shows the only wiring diagram for the component.steering pad switch horn switch assembly, which is found in the car Toyota Avalon XX40 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering pad switch horn switch assembly (1 of 1)
BLK WIRE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
HIGH PITCHED HORN ASSEMBLY
HORN FUSE
HORN RELAY
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (LEFT END OF DASH)
LOW PITCHED HORN ASSEMBLY (LEFT FRONT OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
MAIN HORN BODY ECU (ATTACHED TO INSTRUMENT PANEL J/B)
SPIRAL CABLE HO SUB ASSEMBLY (STEERING COLUMN)
STEERING PAD SWITCH HORN SWITCH ASSEMBLY
WHT WIRE
Go to component -> Horn circuit -> STEERING PAD SWITCH HORN SWITCH ASSEMBLY
