Toyota Avalon XX40 (2012-2015) navigation, seats, power windows systems Wiring diagram
This page shows the only wiring diagram for the component.navigation, seats, power windows systems, which is found in the car Toyota Avalon XX40 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation, seats, power windows systems (1 of 1)
+ECU
4 OF 5)
9 10 PNK DIS WIRE
A/B FUSE
AGND
AGND ACCD
AIR CONDITIONING, SEATS SYSTEMS
BLK WIRE
BRN WIRE
CENTER CONSOLE
CERTIFICATION ECU (RIGHT SIDE OF DASH)
COMPUTER DATA LINES, DOOR LOCKS, ANTI-THEFT, SOUND, NAVIGATION SYSTEMS
ELECTRONIC POWER STEERING SYSTEM
ENGINE SWITCH
FROM
FROM ENGINE ROOM J/B (DIAGRAM 2 OF 5)
FROM INSTRUMENT PANEL J/B (DIAGRAM
FUSE
GND 1 PGND
GRN WIRE
GRY WIRE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
NAVIGATION, SEATS, POWER WINDOWS SYSTEMS
PNK ASEL WIRE
PNK WIRE
RED WIRE
SUPPLEMENTAL RESTRAINTS SYSTEM
TO ENGINE ROOM J/B (DIAGRAM 2 OF 5)
TO INSTRUMENT PANEL J/B (DIAGRAM 5 OF 5)
VIO WIRE
WARNING SYSTEMS
WARNING, SUPPLEMENTAL RESTRAINTS SYSTEMS
WHT WIRE
WHT/BLK WIRE
WIPER/WASHER, MIRRORS, POWER TOPS SYSTEMS
WIRELESS CHARGER ASSEMBLY (IF EQUIPPED) (FRONT OF
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (3 of 5) -> NAVIGATION, SEATS, POWER WINDOWS SYSTEMS
