Toyota Avalon XX40 (2012-2015) dc/ efi- main 2 dc-s main fuse fuse fuse Wiring diagram
This page shows the only wiring diagram for the component.dc/ efi- main 2 dc-s main fuse fuse fuse, which is found in the car Toyota Avalon XX40 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dc/ efi- main 2 dc-s main fuse fuse fuse (1 of 1)
ABS 1 FUSE
ABS 2 FUSE
ABS MTR 1 FUSE R/B 2 FUSE
ABS MTR 2 FUSE
ALT
AMP FUSE FUSE
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
COOLING FANS, AIR CONDITIONING SYSTEMS
D/C CUT
DC/ EFI- MAIN 2 DC-S MAIN FUSE FUSE FUSE
DC/DC FUSE
DOME FUSE
DOOR LOCKS SYSTEM
ECU-B 1 FUSE
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEMS
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE TO ENGINE CONTROLS ROOM J/B SYSTEM (DIAGRAM 2 OF 5)
EPS FUSE
FAN FUSE
FROM ABS 1 FUSE (DIAGRAM 1 OF 5) EFI- MAIN 1 FUSE
FUSIBLE LINK BLOCK (RIGHT SIDE HV BATTERY COMPT) MAIN FUSE
GRN WIRE
GRY WIRE
H-LP- MAIN FUSE
HEADLIGHTS SYSTEM
INSTRUMENT PANEL J/B (LEFT END BECU OF DASH)
INTEGRATION RELAY
LT BLU WIRE
MAIN BODY ECU
NAVIGATION, SOUND SYSTEMS
PNK WIRE
RADIO-B FUSE
RED WIRE
S-HORN FUSE
SMART FUSE
TO EFI-MAIN 1 FUSE (DIAGRAM 1 OF 5)
TO ENGINE ROOM R/B 2 (DIAGRAM 3 OF 5)
TO ETCS FUSE (DIAGRAM 2 OF 5)
TO HTR FUSE (DIAGRAM 2 OF 5)
TO INSTRUMENT PANEL J/B (DIAGRAM 3 OF 5)
TO INSTRUMENT PANEL J/B (DIAGRAM 4 OF 5)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, hybrid (1 of 5) -> DC/ EFI- MAIN 2 DC-S MAIN FUSE FUSE FUSE
