Driver power seat circuit for Toyota Avalon XX30 facelift (2007-2010)

BLK WIRE BLU WIRE BRN WIRE DOWN DRIVER'S POWER SEAT LUMBAR SUPPORT CONTROL MOTOR (UNDER DRIVER'S SEAT) DRIVER'S POWER SEAT LUMBAR SUPPORT CONTROL SWITCH DRIVER'S POWER SEAT SWITCH FRONT FRONT VERTICAL GRN WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) J/C LIFTER P/SEAT FUSE PNK WIRE POWER SEAT MOTOR (DRIVER'S SEAT LIFTER CONTROL) (UNDER DRIVER'S SEAT CUSHION) POWER SEAT MOTOR (DRIVER'S SEAT RECLINING CONTROL) (IN DRIVER'S SEAT) POWER SEAT MOTOR (DRIVER'S SEAT SLIDE CONTROL) (IN DRIVER'S SEAT) REAR RECLINING SLIDE VIO WIRE WHT WIRE YEL WIRE
