Headlamps & fog lamps circuit for Toyota Avalon XX30 facelift (2007-2010)

BEAN I/F BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL ECU DRL RELAY ECU CONTROL LIGHT ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) EXCEPT HID HID GENERATOR GRN WIRE HEAD RELAY HID HOT AT ALL TIMES LEFT HEADLAMP ASSEMBLY LEFT HEADLAMP HIGH RIGHT HEADLAMP HIGH LEFT HEADLIGHT (LOW) LEFT RIGHT LOWER HEAD FUSE LOWER HEAD FUSE LEFT RIGHT UPPER HEAD FUSE UPPER HEAD FUSE LIGHT LOW (HID) LT GRN WIRE MAIN FUSE MICON ORG/ WIRE P-I/P I/F (IG) PNK WIRE RED WIRE RIGHT HEADLAMP ASSEMBLY RIGHT HEADLIGHT (LOW) VIO WIRE WHT/BLK WIRE YEL WIRE

16 23 RCTY 19 4 PKB 6 5 3 2 1 CLTB CLTS CLTE TSR TSL AIR CONDITIONING SYSTEM AUTOMATIC LIGHT CONTROL SENSOR (ON TOP OF DASH) BEAM IND BLK WIRE BLU WIRE BLU/BLK WIRE BODY ECU (ATTACHED TO DRIVER SIDE J/B) BRN WIRE CLTE CLTS CLTB 5 6 COMBINATION METER COMPUTER DATA LINES SYSTEM DCTY DOME FUSE DRIVE IC DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) DRIVER'S SIDE DOOR COURTESY SWITCH (LOWER LEFT "B" PILLAR) ECU- IG 1 ECU-B FUSE FLASH LO HIGH 11 12 FLASH DIMMER SWITCH FOG FUSE FOG RELAY FOG SWITCH FUSE GAUGE 2 FUSE GRN WIRE GRY WIRE HEAD HEAD AUTO HEADLAMP DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) HOT IN ACC OR ON HOT IN ON OR START INTERIOR LIGHTS LCTY LEFT FRONT FOG LAMP LIGHT CONTROL SWITCH OFF TAIL LT BLU WIRE LT GRN WIRE MICRO COMPUTER OFF TAIL 20 19 HEAD AUTO ORG/ WIRE PARKING BRAKE SWITCH (ON PARKING BRAKE PEDAL ASSEMBLY) PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PCTY PNK WIRE POWER SUPPLY CIRCUIT RED WIRE RIGHT FRONT FOG LAMP TAIL FUSE TAIL RELAY VIO WIRE WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE WINDSHIELD WIPER SWITCH ASSEMBLY YEL WIRE
