Cruise control circuit for Toyota Avalon XX30 facelift (2007-2010)

+BM TC VPA EPA VCPA PNK WIRE 2 1 20 44 28 36 35 3 27 55 59 57 56 60 58 +B 8 40 41 49 SPD CCS CANH CANL ACCELERATOR POSITION SENSOR (BEHIND LEFT CENTER OF DASH) BATT MREL IGSW STP BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE COMPUTER DATA LINES SYSTEM EFI 1 FUSE EFI RELAY ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES LT GRN WIRE M- M+ NCA WIRE ORG/ WIRE PNK ETA WIRE PNK WIRE RED WIRE STOP 3 FUSE THROTTLE BODY ASSEMBLY (ON TOP REAR OF ENGINE) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE

15 26 25 11 CANL CANH 3 2 8 PL RL NL BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CAN+ CAN- +B STP COMBINATION METER COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH CRUISE IND DRIVE IC DRIVER SIDE J/B DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ECU-B FUSE ETCS FUSE FL+ FL- FR+ FR- RL+ RL- RR+ RR- GAUGE 1 FUSE GAUGE 2 FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) STOP 1 FUSE HOT IN ON OR START IGN FUSE INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) LEFT FRONT SPEED SENSOR (MOUNTED ON LEFT FRONT WHEEL HUB ASSEMBLY) LEFT REAR SPEED SENSOR (MOUNTED ON LEFT REAR WHEEL HUB ASSEMBLY) LT BLU WIRE LT GRN WIRE MICRO COMPUTER NCA WIRE ON OFF ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (ON TRANSAXLE) PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PNK WIRE RED WIRE RIGHT FRONT SPEED SENSOR (MOUNTED ON RIGHT FRONT WHEEL HUB ASSEMBLY) RIGHT REAR SPEED SENSOR (MOUNTED ON RIGHT REAR WHEEL HUB ASSEMBLY) SET IND SKID CONTROL ECU W/ ACTUATOR (AT RIGHT SIDE OF ENGINE COMPARTMENT) SPIRAL CABLE (ON STEERING COLUMN) STEERING WHEEL PAD STOP LAMP SWITCH (BEHIND LEFT SIDE OF DASH) TRANSMISSION CONTROL ECU VIO WIRE W/ VSC W/O VSC WHT WIRE WHT/BLK WIRE YEL WIRE
