Toyota Avalon XX30 facelift 2 (2010-2012) left headlamp high right headlamp high Wiring diagram
This page shows the only wiring diagram for the component.left headlamp high right headlamp high, which is found in the car Toyota Avalon XX30 facelift 2 (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlamp high right headlamp high (1 of 1)
BEAN I/F
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRL RELAY
ENGINE ROOM J/B
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
EXCEPT HID HID
GENERATOR
GRN WIRE
HEAD RELAY
HEADLAMP ASSEMBLY- RIGHT
HID
HIGH LIGHT CONTROL ECU
HOT AT ALL TIMES
LEFT HEADLAMP (HIGH)
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP ASSEMBLY LOW (HID)
LEFT HEADLAMP HIGH RIGHT HEADLAMP HIGH
LEFT HEADLIGHT (LOW)
LH RH UPR UPR HEAD HEAD FUSE FUSE
LH- LWR HEAD FUSE
LH-LWR HEAD FUSE RH-LWR HEAD FUSE
LH-UPR HEAD FUSE
LOW (HID)
LT GRN WIRE
MAIN FUSE
MICON
ORG/ WIRE
P-I/P I/F (IG)
PNK WIRE
RED WIRE
RH- LWR HEAD FUSE
RH-UPR HEAD FUSE
RIGHT HEADLAMP (HIGH)
RIGHT HEADLIGHT (LOW)
VIO WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlamps & fog lamps circuit (1 of 2) -> LEFT HEADLAMP HIGH RIGHT HEADLAMP HIGH
