Toyota Avalon XX30 facelift 2 (2010-2012) left front turn signal, parking lamp Wiring diagrams
This page contains all the electrical diagrams for the component. left front turn signal, parking lamp, in which he is found in the car Toyota Avalon XX30 facelift 2 (2010-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front turn signal, parking lamp (1 of 2)
11 25 CANH CANL COMPUTER DATA LINES SYSTEM
ALT FUSE
AUXILIARY LIGHT (LIGHT PIPE)
AUXILIARY LIGHT (LIGHT PIPE) RIGHT HEADLAMP ASSEMBLY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CENTER STOP LAMP
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM J/B
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
INSTRUMENT PANEL J/B
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LAMP
LEFT "C" PILLAR)
LEFT FRONT RIGHT FRONT TURN SIGNAL, TURN SIGNAL, PARKING LAMP PARKING LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL, PARKING LAMP
LEFT HEADLAMP ASSEMBLY
LEFT OUTER REAR VIEW MIRROR
LT GRN WIRE
NOISE FILTER (DOME, STOP)
NOISE FILTER (DOME, STOP) (LEFT "C" PILLAR)
PARKING
PNK 6 1 7 WIRE
PNK WIRE
POWER SOURCE CONTROL ECU
RED WIRE
RIGHT FRONT SIDE MARKER
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL, PARKING LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR
SHIFT LOCK CONTROL ECU
SHIFT LOCK CONTROL ECU (UNDER CENTER FLOOR CONSOLE, NEAR PARKING BRAKE LEVER)
SKID CONTROL ECU W/ ACTUATOR
SKID CONTROL ECU W/ ACTUATOR (RIGHT SIDE OF ENGINE COMPT)
STOP 1 FUSE
STOP 2 FUSE
STOP 3 FUSE
STOP LAMP SWITCH
STOP LAMP SWITCH (BEHIND LEFT SIDE OF DASH)
TRANSMISSION CONTROL ECU
TURN
VIO WIRE
W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> LEFT FRONT TURN SIGNAL, PARKING LAMP
Wiring diagram left front turn signal, parking lamp (2 of 2)
A/F RELAY
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD
AMBIENT TEMPERATURE SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRAKE WIRELESS FLUID LEVEL DOOR WARNING LOCK SWITCH BUZZER
BRN WIRE
CANISTER PUMP MODULE
COOLING FAN ECU
CRANKSHAFT POSITION SENSOR SHIELD
DATA LINK CONNECTOR 3
DATA LINK SPIRAL CONNECTOR 3 CABLE
EFI RELAY
ENGINE CONTROL MODULE
ENGINE HOOD COURTESY SWITCH
ENGINE ROOM J/B
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B
ENGINE ROOM R/B (LEFT SIDE HEAD RELAY
FAN 1 RELAY
GRY WIRE
HEAD RELAY
HEADLAMP LEVELING ECU
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
HEATED OXYGEN SENSOR (BANK 2 SENSOR 2) SHIELD
HID
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION IGNITION COIL 1 COIL 2
IGNITION IGNITION COIL 6 COIL 5
KNOCK CONTROL SENSOR (BANK 1, 2) SHIELD
LEFT FRONT FOG LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL, PARKING LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HIGH HEADLAMP
LEFT LOW HEADLAMP
MICON
NCA WIRE
OF ENGINE COMPT)
PNK WIRE
RED WIRE
RIGHT END OF DASH)
SKID CONTROL ECU W/ ACTUATOR
SPIRAL CABLE
ST CUT RELAY
ST RELAY
ST RELAY RELAY
TOP OF ENGINE)
TRANSMISSION CONTROL ECU
W/ SMART KEY
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR
WIP (HI/LO) RELAY
WIP CTRL RELAY
WIRELESS DOOR LOCK BUZZER
Go to component -> Ground distribution circuit (1 of 4) -> LEFT FRONT TURN SIGNAL, PARKING LAMP
