Toyota Avalon XX30 facelift 2 (2010-2012) head light control switch wiring diagram
This page shows the only wiring diagram for the component.head light control switch, which is found in the car Toyota Avalon XX30 facelift 2 (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
head light control switch wiring diagram (1 of 1)
+B (DOME)
1 2 3 4 5 6 7 8 IG LR LL
16 14 RCTY DCTY
23 21 PCTY
AUTO
AUTO DRL OFF AUTO TAIL
AUTO TAIL
BLK WIRE
BLU WIRE
BODY ECU
BODY ECU (ATTACHED TO DRIVER SIDE J/B)
BRN WIRE
CANADA
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DCTY
DOME FUSE
DRIVE IC
DRL OFF
ECU B+
ECU- IG 1 FUSE
ECU-B FUSE
EL ER
ENGINE ROOM R/B
GAUGE 1 FUSE
GRN WIRE
GRY WIRE
HAZARD WARNING SIGNAL SWITCH
HEAD
HEAD IND
HEAD LIGHT CONTROL SWITCH
HEADLAMP DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) TURN/ HAZ FUSE
INSTRUMENT PANEL J/B
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) STP
INTERIOR LIGHT SYSTEM
LCTY
LEFT
LEFT "C" PILLAR)
LEFT REAR COMBINATION LAMP
LEFT TURN IND
LICENSE PLATE LAMP
LIGHT CONTROL SWITCH
LT GRN WIRE
MICRO COMPUTER
OFF
OFF TAIL HEAD
ORG/ WIRE
PCTY
PNK 1 2 5 WIRE
PNK 1 WIRE
PNK 2 PNK 1 WIRE
PNK WIRE
POWER SUPPLY CIRCUIT
RCTY
RED WIRE
RELAY ENERGIZED
RELAY ENERGIZED INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) ECU IG 1 FUSE
RIGHT
RIGHT REAR COMBINATION LAMP
RIGHT TURN IND
SIDE MARKER
STOP
STOP TAIL
TAIL
TAIL FUSE
TAIL HEAD IND IND (EXCEPT (USA) USA) (LEFT DRIVE IC "C" PILLAR)
TAIL IND
TAIL RELAY
TAIL STOP TAIL
TAIL TAIL STOP/ TURN
TAIL TURN
TRNL
TRNR
TRNR LCTY
TURN
TURN RIGHT SWITCH
TURN SIGNAL FLASHER
TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH)
TURN SWITCH
TURN, HAZ FUSE
USA
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> HEAD LIGHT CONTROL SWITCH
