Charging circuit for Toyota Avalon XX30 (2005-2007)

ALT FUSE BATTERY BATTERY GROUND BLK WIRE BLU WIRE BRN WIRE COMBINATION METER DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) ALT FUSE EUC-B FUSE ALT-S FUSE GENERATOR GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IND CHARGE INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) GAUGE 1 FUSE INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) GAUGE 2 FUSE JUNCTION CONNECTOR MAIN FUSIBLE LINK (12 GA- MICON NCA WIRE ORG/ WIRE P-I/P I/F (IG) POWER SUPPLY CIRCUIT RED WIRE W/ SMART KEY W/O SMART KEY WHT WIRE YEL WIRE
