Toyota Avalon XX30 (2005-2007) Shift interlock circuit

1 2 3 4 5 6 7 8 9 10 11 12 IG BLK WIRE BLU WIRE DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ECU-ACC FUSE ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) ECU IG 1 FUSE J/C KLS+ NCA WIRE PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PNK WIRE POWER SOURCE CONTROL ECU (W/ SMART KEY SYSTEM) (BEHIND RIGHT SIDE OF DASH) RED WIRE SHIFT LOCK CONTROL ECU (UNDER CENTER FLOOR CONSOLE, NEAR PARKING BRAKE LEVER) SLS+ SLS+ SHIFT LOCK SOLENOID STOP 1 FUSE STOPLIGHT SWITCH (BEHIND LEFT SIDE OF DASH) UNLOCK WARNING SWITCH (W/O SMART KEY SYSTEM) (LOWER LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
