Immobilizer circuit, with smart key system for Toyota Avalon XX30 (2005-2007)

1 2 3 4 5 6 7 8 MPXB 15 16 IMO IMI BLU WIRE BRN WIRE EFII EFIO ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT) HOT AT ALL TIMES IMMOBILIZER CODE ECU (BEHIND LEFT SIDE OF DASH) IMMOBILIZER FUSE JUNCTION CONNECTOR 52 (LEFT FRONT OF ENGINE COMPARTMENT) LIN PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH) RED WIRE SMART KEY ECU (BEHIND RIGHT SIDE OF DASH) STEERING LOCK ECU (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE
