Toyota Avalon XX30 (2005-2007) steering wheel pad right steering switch Wiring diagram
This page shows the only wiring diagram for the component.steering wheel pad right steering switch, which is found in the car Toyota Avalon XX30 (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel pad right steering switch (1 of 1)
21 13 11 2 22 ILL- ILL+ PSE PIL+ PIL-
8 10 18 ILL- ILL+ SE
A/C CONTROL ASSEMBLY
A/O
BLK WIRE
BLU WIRE
BODY ECU (ATTACHED TO DRIVER SIDE J/B) TRLY
BRN WIRE
CIGAR LIGHTER
CILL
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CSPT
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
EAU
ECU- IG 1 FUSE
ECU-B FUSE DOME FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
GAUGE 2 FUSE
GLOVE BOX LAMP)
GRN WIRE
GRY WIRE
HAZARD WARNING SIGNAL SWITCH
HEAD TAIL
HOT AT ALL TIMES
HOT IN ON OR START
IL+2
ILL ILL
ILLUMINATION
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
LED ILLUMINATION
LEFT STEERING SWITCH
LT GRN WIRE
MAP LAMP
NAVIGATION CONTROLLER (W/ NAVIGATION)
OFF HEAD
ORG/ WIRE
PANEL FUSE
POINTER ILLUMINATION
POWER SUPPLY CIRCUIT
RADIO RECEIVER ASSEMBLY
RED WIRE
RHEOSTAT
SEAT HEATER SWITCH (W/ SEAT HEATER)
SPIRAL CABLE (ON STEERING COLUMN)
STEERING WHEEL PAD RIGHT STEERING SWITCH
SWITCH LIGHT CONTROL
TAIL CANCEL SWITCH
TAIL OFF HEADLAMP DIMMER SWITCH ASSEMBLY
TAIL RELAY
TEMPERATURE CONTROL SWITCH ASSEMBLY
TRANSMISSION CONTROL SWITCH
VIO WIRE
W/ 12 SPEAKER W/ 9 SPEAKER
W/ SMART KEY W/O SMART KEY W/ NAVIGATION W/ DYNAMIC CRUISE CONTROL
WHT WIRE
WHT/BLK WIRE
WINDSHIELD DIMMER SWITCH ASSEMBLY
YEL WIRE
Go to component -> Instrument illumination circuit -> STEERING WHEEL PAD RIGHT STEERING SWITCH
