Toyota Avalon XX30 (2005-2007) sol- flow control value Wiring diagram

3 2 1 +B SI GND 33 34 CANH CANL TACH A/C AMPLIFIER (RIGHT SIDE OF DASH) A/C BLOWER ASSEMBLY A/C COMPRESSOR (RIGHT FRONT OF ENGINE COMPARTMENT) A/C EVAPORATOR TEMPERATURE SENSOR A/C PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPARTMENT) A/C ROOM TEMPERATURE SENSOR (BEHIND CENTER OF DASH) AIR INLET DAMPER SERVO MOTOR AUTOMATIC LIGHT CONTROL SENSOR (ON TOP OF DASH) B+ BUS BLK WIRE BLK/WHT WIRE BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH) BLU WIRE BRN WIRE BUS - BUS G COMBINATION METER COMPUTER DATA LINES SYSTEM DAMPER SERVO MOTOR DAMPER SERVO MOTOR (AIR MIX DRIVER SIDE) DAMPER SERVO MOTOR (AIR VENT MODE) DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE COOLANT TEMPERATURE SENSOR (ON TOP REAR OF ENGINE) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT) HEATER FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOUSING COLOR (BLUE) SMART CONNECTOR HOUSING COLOR (RED) SMART CONNECTOR WIRE INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) A/C FUSE LOCK SENSOR LT BLU WIRE LT GRN WIRE MAGNETIC CLUTCH MG+ MGC SOL+ LOCK BLW PRE TSP TR SG-3 SG-1 GND IG+ ORG/ WIRE PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PNK WIRE RED WIRE SGA SMART CONNECTOR HOUSING COLOR (BLACK) SMART CONNECTOR HOUSING COLOR (GREEN) SOL + SOL- FLOW CONTROL VALUE SSR+ TACO MPX+ MPX- TSD SG-2 TEA TSL TSR VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
