Toyota Avalon XX30 (2005-2007) right tw+ rear tweeter Wiring diagram
This page shows the only wiring diagram for the component.right tw+ rear tweeter, which is found in the car Toyota Avalon XX30 (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right tw+ rear tweeter (1 of 1)
-TW
1 2 3 4 5 6 7 8 9 10 +B SR+ RL+ RR-
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 MUTE L- L+ R- R+
1 2 3 4 5 6 7 8 9 10 11 12 FL- FL+ FR- SL+ PNK WIRE
10 1 2 11 AUI- AUI+ AUO+ AUO-
AMP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CENTER SPEAKER
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FR+ SL-
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT TWEETER
LEFT REAR DOOR SPEAKER
LEFT TW- TW+ REAR TWEETER
LT GRN WIRE
NAVIGATION ECU (W/ NAVIGATION) (LEFT SIDE OF LUGGAGE COMPT)
PNK WIRE
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER LEFT FRONT DOOR SPEAKER
RIGHT TW+ REAR TWEETER
RIGHT TWR+ FRONT TWEETER
SPEAKER (LEFT PACKAGE TRAY)
SPEAKER (RIGHT PACKAGE TRAY)
SPEAKER (WOOFER)
SR- CTR- CTR+ RL- RR+
TWL-
TWR+
TX- TX+
VIO WIRE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 12-speaker system circuit (2 of 2) -> RIGHT TW+ REAR TWEETER
