Toyota Avalon XX30 (2005-2007) head ind tail ind Wiring diagram

19 2 SPD TACH 8 1 SPD TACH A/C AMPLIFIER (RIGHT SIDE OF DASH) A/O A/T LCD ACAN ACTIVE CIRCUIT SRS IND ANTI-LOCK BRAKES SYSTEM ANTI-THEFT SYSTEM BEAN I/F BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRAKE FLUID LEVEL WARNING SWITCH (ON BRAKE FLUID RESERVOIR) BRAKE IND BRN WIRE BUZZER CHARGE IND CLOCK (W/ NAVIGATION) COMBINATION METER COMPUTER DATA LINES SYSTEM DOOR IND (USA) (EXCEPT USA) DRIVER'S SEAT BELT IND DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ECU-ACC FUSE ECU-B FUSE ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE CONTROLS SYSTEM HEADLIGHTS SYSTEM ENGINE OIL PRESSURE SWITCH (ON LEFT SIDE OF ENGINE) ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) DOME FUSE FUEL GAUGE FUEL IND GAUGE 2 FUSE GRN WIRE GRY WIRE HEAD IND TAIL IND HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START ILLUM INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) LCD (ACC) LCD ODO/TRIP LED ILLUM LEFT TURN IND RIGHT TURN IND LT BLU WIRE LT GRN WIRE MAINT REQD IND MALFUNCTION IND LAMP HEADLIGHT BEAM LEVEL IND MICON MULTI-DISPLAY (W/ NAVIGATION) MULTI-INFORMATION SYSTEM CIRCUIT WARNING SYSTEM NAVIGATION ECU (LEFT SIDE OF LUGGAGE COMPT) OIL PRESSURE IND ORG/ WIRE P-I/P I/F (IG) PARKING BRAKE SWITCH (ON PARKING BRAKE PEDAL ASSEMBLY) PKB BODY ECU PNK WIRE POINTER ILLUM POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH) POWER SUPPLY CIRCUIT RANGE RED WIRE SECURITY IND SPEEDOMETER SUPPLEMENTAL RESTRAINTS SYSTEM TACHOMETER MPX +B TACO TEMP GAUGE VIO WIRE W/ NAVIGATION W/O NAVIGATION WASHER LEVEL IND WHT WIRE WHT/BLK WIRE YEL WIRE
