Toyota Avalon XX30 (2005-2007) hazard warning signal switch Wiring diagrams
This page contains all the electrical diagrams for the component. hazard warning signal switch, in which he is found in the car Toyota Avalon XX30 (2005-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hazard warning signal switch (1 of 3)
1 2 3 4 5 6 7 8 IG LR LL PNK WIRE
BLK WIRE
BLU WIRE
BODY ECU
BODY ECU (ATTACHED TO DRIVER SIDE J/B)
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOME FUSE
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
ECU-B FUSE
EL ER
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT) TURN/ HAZ FUSE
GAUGE 1 FUSE
GRN WIRE
GRY WIRE
HAZARD WARNING SIGNAL SWITCH
HEADLAMP DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) ECU IG 1 FUSE
JUNCTION CONNECTOR
LAMP
LEFT
LEFT FRONT SIDE MARKER LAMP
LEFT REAR COMBINATION LAMP TURN
LEFT REAR OUTER VIEW MIRROR (W/ MEMORY) RIGHT REAR OUTER VIEW MIRROR (W/ MEMORY)
LEFT TURN IND
LICENSE PLATE LAMP
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
RIGHT
RIGHT FRONT SIDE MARKER
RIGHT REAR COMBINATION LAMP STOP TURN
RIGHT TURN IND
TAIL
TAIL FUSE
TAIL IND (EXCEPT USA)
TAIL RELAY
TAIL STOP
TAIL TAIL
TRNL
TRNR
TURN
TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> HAZARD WARNING SIGNAL SWITCH
Wiring diagram hazard warning signal switch (2 of 3)
A/C AMPLIFIER
A/C CONTROL ASSEMBLY
BLK WIRE
BLOWER MOTOR
BODY ECU
CENTER AIR BAG SENSOR ASSEMBLY
CIGARETTE LIGHTER
CLOCK
COMBINATION METER MULTI- DISPLAY
DATA LINK CONNECTOR 3
DOOR LOCK CONTROL SWITCH
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
GLOVE BOX LAMP)
HAZARD WARNING SIGNAL SWITCH
IMMOBILIZER CODE ECU SMART A/C COMPRESSOR KEY ECU
LEFT FRONT DOOR ELECTRICAL KEY OSCILLATOR
MEMORY SWITCH
MIRROR CONTROL ECU
MULTI-DISPLAY
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
POWER OUTLET 1
POWER OUTLET 2
REAR SUNSHADE SWITCH
REAR WINDOW DEFOGGER
RELAY
RIGHT OUTER REAR VIEW MIRROR
STEERING LOCK ECU
TAIL RELAY POWER RELAY RELAY
TELLTALE LAMP ASSEMBLY
TO DRIVER SIDE J/B (DIAGRAM 2 OF 4)
TO MAP LAMP (DIAGRAM 2 OF 4)
W/ MEMORY
W/ SMART KEY
W/O NAVIGATION
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> HAZARD WARNING SIGNAL SWITCH
Wiring diagram hazard warning signal switch (3 of 3)
