Toyota Avalon XX30 (2005-2007) engine rom r/b (on left side of engine ecu-b fuse Wiring diagram
This page shows the only wiring diagram for the component.engine rom r/b (on left side of engine ecu-b fuse, which is found in the car Toyota Avalon XX30 (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine rom r/b (on left side of engine ecu-b fuse (1 of 1)
+ECU
1 2 3 4 5 6 7 8 9 10 PWS
BECU DCTY
BLK WIRE
BLU WIRE
COMPT)
DOOR COURTESY SWITCH (DRIVER'S SIDE) (LOWER LEFT "B" PILLAR)
DOWN
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
ENGINE ROM R/B (ON LEFT SIDE OF ENGINE ECU-B FUSE
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IG DWN UP
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
ORG/ WIRE
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
PNK WIRE
PWS
SLIDE OPEN
SLIDING ROOF CONTROL ECU (FRONT OF ROOF)
SLIDING ROOF CONTROL SWITCH
SLIDING ROOF ECU
SLIDING ROOF MOTOR
SUN ROOF FUSE
UP TILT UP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> ENGINE ROM R/B (ON LEFT SIDE OF ENGINE ECU-B FUSE
