Toyota Avalon XX30 (2005-2007) driver's power seat lumbar support control switch Wiring diagram
This page shows the only wiring diagram for the component.driver's power seat lumbar support control switch, which is found in the car Toyota Avalon XX30 (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's power seat lumbar support control switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DOWN
DRIVER'S POWER SEAT LUMBAR SUPPORT CONTROL MOTOR (UNDER DRIVER'S SEAT)
DRIVER'S POWER SEAT LUMBAR SUPPORT CONTROL SWITCH
DRIVER'S POWER SEAT SWITCH
FRONT
FRONT VERTICAL SLIDE
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C
LIFTER
P/SEAT FUSE
PNK WIRE
POWER SEAT MOTOR (DRIVER'S SEAT LIFTER CONTROL) (UNDER DRIVER'S SEAT CUSHION)
POWER SEAT MOTOR (DRIVER'S SEAT RECLINING CONTROL) (IN DRIVER'S SEAT)
REAR
RECLINING
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> DRIVER'S POWER SEAT LUMBAR SUPPORT CONTROL SWITCH
