Toyota Avalon XX30 (2005-2007) ctsw slr+ Wiring diagram
This page shows the only wiring diagram for the component.ctsw slr+, which is found in the car Toyota Avalon XX30 (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ctsw slr+ (1 of 1)
ACCD
ACCR
AGND
ANTENNA COIL
ANTI-THEFT SYSTEM
ANTI-THEFT SYSTEM, SHIFT INTERLOCK SYSTEM
BATTERY
BATTERY GROUND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CODE
COMPUTER DATA LINES SYSTEM
CTSW SLR+
DRIVER SIDE J/B
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
INDS
INDS PNK WIRE
INDW
INSTRUMENT CLUSTER SYSTEM
JUNCTION CONNECTOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
P/N
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
POWER SWITCH
RDA STSW
RED WIRE
RELAY
SHIFT INTERLOCK SYSTEM
SHIFT INTERLOCK SYSTEM INSTRUMENT CLUSTER
SLP
SMART KEY ECU (BEHIND RIGHT SIDE OF DASH)
STAR
STARTER
STARTER CUT RELAY
STARTER RELAY
STSW
SWIL
SYSTEM
TXCT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Starting circuit, with smart key system -> CTSW SLR+
