Toyota Avalon XX30 (2005-2007) center air bag sensor assembly Wiring diagram
This page shows the only wiring diagram for the component.center air bag sensor assembly, which is found in the car Toyota Avalon XX30 (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center air bag sensor assembly (1 of 1)
A/C AMPLIFIER
A/C CONTROL ASSEMBLY
BLK WIRE
BLOWER MOTOR
BODY ECU
CENTER AIR BAG SENSOR ASSEMBLY
CIGARETTE LIGHTER
CLOCK
COMBINATION METER MULTI- DISPLAY
DATA LINK CONNECTOR 3
DOOR LOCK CONTROL SWITCH
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
GLOVE BOX LAMP)
HAZARD WARNING SIGNAL SWITCH
IMMOBILIZER CODE ECU SMART A/C COMPRESSOR KEY ECU
LEFT FRONT DOOR ELECTRICAL KEY OSCILLATOR
MEMORY SWITCH
MIRROR CONTROL ECU
MULTI-DISPLAY
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
POWER OUTLET 1
POWER OUTLET 2
REAR SUNSHADE SWITCH
REAR WINDOW DEFOGGER
RELAY
RIGHT OUTER REAR VIEW MIRROR
STEERING LOCK ECU
TAIL RELAY POWER RELAY RELAY
TELLTALE LAMP ASSEMBLY
TO DRIVER SIDE J/B (DIAGRAM 2 OF 4)
TO MAP LAMP (DIAGRAM 2 OF 4)
W/ MEMORY
W/ SMART KEY
W/O NAVIGATION
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> CENTER AIR BAG SENSOR ASSEMBLY
