Toyota Avalon XX30 (2005-2007) brk relay Wiring diagrams
This page contains all the electrical diagrams for the component. brk relay, in which he is found in the car Toyota Avalon XX30 (2005-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brk relay (1 of 2)
ABS/ VSC 1 FUSE
ABS/ VSC 2
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BM FR+ FL- RR+ RL- PNK WIRE
BRK RELAY
BRN WIRE
BZ +BS
D/G
D/G MRF MR STPO FR- FL+ RR- RL+
DATA LINK CONNECTOR 3 (AT LOWER LEFT SIDE OF DASH)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HUB ASSEMBLY)
INSTRUMENT PANEL J/B
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) ECU IG 2 FUSE
JUNCTION CONNECTOR
LEFT FRONT SPEED SENSOR
LEFT REAR SPEED SENSOR
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (ON PARKING BRAKE PEDAL ASSEMBLY)
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
PNK 12 13 WIRE
PNK WIRE
RED WIRE
RIGHT FRONT SPEED SENSOR (MOUNTED ON RIGHT FRONT WHEEL
RIGHT REAR SPEED SENSOR
RLO
RRO HEADLAMP LEVELING ECU (BEHIND LEFT SIDE OF DASH)
RRO RLO
SKID CONTROL ECU W/ ACTUATOR (AT RIGHT SIDE OF ENGINE COMPT)
TS CANL
VIO WIRE
VSC 1 RELAY
VSC 2 RELAY
WFSE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, with traction control (1 of 2) -> BRK RELAY
Wiring diagram brk relay (2 of 2)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRK RELAY
BRN WIRE
CENTER STOP LAMP
ECU-IG 2 FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
JUNCTION
JUNCTION CONNECTOR
LEFT FRONT TURN SIGNAL, PARKING LAMP
NOISE FILTER (DOME, STOP) (LEFT "C" PILLAR)
PARKING
PNK WIRE
RADAR CC FUSE
RIGHT FRONT TURN SIGNAL, PARKING LAMP
SKID CONTROL ECU W/ ACTUATOR (AT RIGHT SIDE OF ENGINE COMPT)
STOP 1 FUSE
STOP 2 FUSE
STOP LAMP SWITCH (BEHIND LEFT SIDE OF DASH)
TURN
VIO WIRE
W/ VSC
W/O DYNAMIC RADAR CRUISE CONTROL
W/O VSC
WHT WIRE
WHT/BLK WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> BRK RELAY
