Toyota Avalon XX30 (2005-2007) +5 data asel rssi gnd ant Wiring diagram

+5 DATA ASEL RSSI GND ANT 1 2 3 4 5 GND RDA PRG 16 4 PNK WIRE ANT BEAN I/F BLK WIRE BLU WIRE BRN WIRE BUZZER COMBINATION METER COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM PNK WIRE DOOR CONTROL RECEIVER (AT RIGHT "C" PILLAR) DOOR IND DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) DRIVER'S SIDE DOOR COURTESY SWITCH (LOWER LEFT "B" PILLAR) ELECTRICAL KEY ANTENNA (W/ SMART KEY) (IN LUGGAGE COMPARTMENT) ENGINE ROOM J/B GATEWAY ECU (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRY WIRE HEAD HORN RELAY HORNS SYSTEM HOT AT ALL TIMES LT GRN WIRE MI SIDE I/F (+B) MICON ORG/ WIRE P-I/P I/F PASSENGER SIDE J/B (W/O SMART KEY) (BEHIND RIGHT SIDE OF DASH) PNK 1 2 3 4 5 WIRE PNK WIRE POWER SOURCE CONTROL ECU (W/ SMART KEY) (BEHIND RIGHT SIDE OF DASH) RED WIRE RSSI ASEL RDA RCO S-HORN FUSE SECURITY HORN RELAY SECURITY IND SUPPLY TRANSPONDER KEY AMPLIFIER (W/O SMART KEY) (IN STEERING COLUMN) UNLOCK WARNING SWITCH (W/O SMART KEY) (LOWER LEFT SIDE OF DASH) VIO WIRE W/O SMART KEY W/ SMART KEY WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER SWITCH ASSEMBLY YEL WIRE
