Toyota Avalon XX30 (2005-2007) 4 1 21 cpub gnd sel 1 Wiring diagram
This page shows the only wiring diagram for the component.4 1 21 cpub gnd sel 1, which is found in the car Toyota Avalon XX30 (2005-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 1 21 cpub gnd sel 1 (1 of 1)
16 4 PNK WIRE
4 1 21 CPUB GND SEL 1
4 1 CPUB GND
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BUZZER
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CTY
DOME FUSE
DOOR 1 FUSE
DOOR IND
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
DRIVER'S SIDE DOOR COURTESY SWITCH (LOWER LEFT "B" PILLAR)
ECU-B FUSE
ELECTRONIC KEY IND
ENGINE ROOM R/B
GRN WIRE
GRY WIRE
HEAD RELAY
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
IMMOBILIZER FUSE
LEFT OUTER MIRROR CONTROL ECU (IN DRIVER`S DOOR)
LEFT OUTER REAR VIEW MIRROR
LT GRN WIRE
MAIN FUSE
MAP LAMP
ORG/ WIRE
PNK 1 2 3 4 5 6 7 WIRE
PNK WIRE
RED WIRE
RIGHT OUTER MIRROR CONTROL ECU (IN RIGHT FRONT DOOR)
RIGHT OUTER REAR VIEW MIRROR
ROOM LAMP
VIO WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power door locks circuit, with smart key system (2 of 4) -> 4 1 21 CPUB GND SEL 1
