Toyota Avalon XX30 (2005-2007) 2 4 3 5 7 6 +5 asel data rssi ant gnd Wiring diagram

2 4 3 5 7 6 +5 ASEL DATA RSSI ANT GND ANT BEAN I/F BLK WIRE BLU WIRE BLU/YEL WIRE BRN WIRE CLG CLGB COMPUTER DATA LINES SYSTEM DOOR CONTROL RECEIVER (AT RIGHT "C" PILLAR) ELECTRICAL KEY ANTENNA (IN LUGGAGE COMPARTMENT) ENGINE COMPT) ENGINE ROOM J/B GRN WIRE GRN/WHT WIRE HORN RELAY HORNS SYSTEM HOT AT ALL TIMES IMMOBILIZER CODE ECU (BEHIND LEFT SIDE OF DASH) LEFT FRONT DOOR ELECTRICAL KEY OSCILLATOR (IN DRIVER'S DOOR) LEFT FRONT DOOR OUTSIDE HANDLE LIN LT GRN WIRE MI SIDE I/F (+B) MICON ORG/ WIRE PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PNK WIRE POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH) RED WIRE RED/WHT WIRE RIGHT FRONT DOOR ELECTRICAL KEY OSCILLATOR (IN RIGHT FRONT DOOR) RIGHT FRONT DOOR OUTSIDE HANDLE S-HORN FUSE SECURITY HORN (RIGHT REAR OF SECURITY HORN RELAY SEL SENS SGT STEERING LOCK ECU (BEHIND LEFT SIDE OF DASH) TRG+ VIO WIRE WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER SWITCH ASSEMBLY 4 6 HEAD YEL WIRE
