Toyota Avalon XX30 (2005-2007) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 +b ig ksw txct agnd Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 +B IG KSW TXCT AGND 15 16 IMO IMI 4 1 7 5 CODE AGND TXCT BATT MREL IGSW BLK WIRE BLU WIRE BRN WIRE CODE GND COMBINATION METER COMPARTMENT) CTY IND PNK WIRE DATA LINK CONNECTOR 3 (AT LOWER LEFT SIDE OF DASH) DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) DRIVER'S SIDE DOOR COURTESY SWITCH (LOWER LEFT "B" PILLAR) ECU-B FUSE EFI 1 FUSE EFI RELAY EFII EFIO ENGINE CONTROL MODULE (BEHIND ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPARTMENT) IGN FUSE ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IMMOBILIZER FUSE INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) KEY COIL TRANSPONDER LT GRN WIRE ORG/ WIRE PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PNK WIRE RED WIRE SECURITY IND SIL TRANSPONDER KEY AMPLIFIER (IN STEERING COLUMN) TRANSPONDER KEY ECU (BEHIND LEFT SIDE OF DASH) UNLOCK WARNING SWITCH (LOWER LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
