Immobilizer circuit for Toyota Avalon XX20 facelift (2002-2005)

1 2 3 4 5 +B CODE RXCK TXCT GND 2 1 22 8 16 IGSW BATT IMLD MREL +B 28 19 18 CODE RXCK TXCT BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLU/ORG WIRE BLU/YEL WIRE BRN WIRE COMBINATION METER TRANS- PONDER KEY COIL DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ED (AT FRONT OF LEFT FRONT FENDER) EFI 1 FUSE EFI 2 FUSE EFI RELAY ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE ROOM J/B (ON LEFT FRONT INNER FENDER PANEL) EOM KSW HOT AT ALL TIMES IG (AT LEFT END OF DASH) IGNITION SWITCH II (RIGHT KICK PANEL) J/B 4 (BEHIND RIGHT KICK PANEL) J/B 4 (RIGHT KICK PANEL) J/C 17 (BEHIND CENTER OF DASH) J/C 5 (BEHIND RIGHT SIDE OF DASH) J/C 6 (BEHIND RIGHT CENTER OF DASH) OFF PNK/GRN WIRE RED/YEL WIRE SECURITY INDICATOR TRANSPONDER KEY AMPLIFIER (ON LEFT SIDE OF DASH, ON STEERING COLUMN) UNLOCK WARNING SWITCH VIO/WHT WIRE WHT WIRE WHT/BLK WIRE
