Manual a/c circuit for Toyota Avalon XX20 (1999-2002)

1 2 3 5 6 DEF F/D FOOT B/L FACE A/C DIODE (BEHIND LEFT KICK PANEL) A/C FUSE A/CB A/C- AIR INLET CONTROL SERVO MOTOR (ON HVAC HOUSING) AIR OUTLET CONTROL SERVO MOTOR (ON HVAC HOUSING) BLK WIRE BLK/WHT WIRE BLOWER RESISTOR (BEHIND LEFT CENTER OF DASH) BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ECU-B FUSE ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE ROOM R/B 5 (ON LEFT INNER FENDER PANEL) FRS GRN WIRE GRN/RED WIRE GRY WIRE HEATER CONTROL SWITCH HOT IN ON OR START HTR FUSE HTR RELAY IG+ LA/C FACE B/L FOOT F/D DEF FRS REC J/B 3 (BEHIND LEFT KICK PANEL) J/B 3 (BEHIND RIGHT KICK PANEL) J/C 1 (TOP OF LEFT KICK PANEL) J/C 6 (BEHIND RIGHT CENTER OF DASH) LT GRN/BLK WIRE LT GRN/RED WIRE MULTI-DISPLAY OFF PNK WIRE REC RED WIRE RED/BLU WIRE RED/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/GRN WIRE

A/C AMBIENT TEMPRATURE SENSOR (LOWER RIGHT FRONT OF GRILLE) A/C MAGNETIC CLUTCH, LOCK SENSOR (ON A/C COMPRESSOR) A/C THERMISTOR (BEHIND CENTER OF DASH) A/C TRIPLE PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE CDS FUSE DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) DUAL PRESS ECU-IG FUSE ENGINE ROOM J/B (LEFT FRONT INNER FENDER PANEL) ENGINE ROOM J/B (LEFT INNER FENDER PANEL) ENGINE ROOM R/B 3 (LEFT FRONT OF ENGINE COMPT) FAN 1 RELAY FAN 2 RELAY FAN 3 RELAY GRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ON OR START J/B 3 (BEHIND LEFT KICK PANEL) LEFT FRONT FENDER) LT GRN/BLK WIRE MG/CLT RELAY PNK WIRE RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPT) RDI FUSE RED WIRE RED/WHT WIRE SINGLE PRESS WATER TEMPRATURE SWITCH 1 (TOP REAR OF INTAKE MANIFOLD) WATER TEMPRATURE SWITCH 2 (TOP REAR OF INTAKE MANIFOLD) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
