Toyota Avalon XX10 facelift (1997-2000) Courtesy lamps circuit

BR BR AR BR AR CENTER J/B (BEHIND RIGHT SIDE OF DASH) CIG/ RADIO FUSE COMBINATION METER DIODE (INTERIOR LIGHT) FRONT PERSONAL LIGHT (W/ MOON ROOF) FRONT PERSONAL LIGHT (W/O MOON ROOF XLS GRADE) GAUGE FUSE GRN/RED WIRE HOT AT ALL TIMES ENGINE ROOM J/B (LEFT INNER FENDER PANEL) DOME FUSE HOT IN ACC OR ON HOT IN ON OR START IGNITION KEY CYLINDER LIGHT INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) INTEGRATION RELAY LEFT FRONT DOOR COURTESY LIGHT LEFT FRONT DOOR COURTESY SWITCH LEFT REAR DOOR COURTESY SWITCH LEFT REAR PERSONAL LIGHT (XLS GRADE) LEFT VANITY LIGHT LUGGAGE COMP. LIGHT SWITCH LUGGAGE COMPARTMENT LIGHT NOISE FILTER (XLS GRADE) (RIGHT SIDE OF REAR WINDOW) OFF OFF DOOR INTERIOR LIGHT (W/MOON ROOF, XL GRADE W/O MOON ROOF) ON DOOR OPEN DOOR WARNING LIGHT ORG/ WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FRONT DOOR COURTESY LIGHT RIGHT FRONT DOOR COURTESY SWITCH RIGHT REAR DOOR COURTESY SWITCH RIGHT REAR PERSONAL LIGHT (XLS GRADE) RIGHT VANITY LIGHT USA XLS GRADE AND CANADA USA XL GRADE USA XLS GRADE, CANADA WHT/BLK WIRE
