A/c circuit, manual a/c for Toyota Avalon XX10 facelift (1997-2000)

1 2 CONTROL CIRCUIT 1995 VFTC A/C A/C AMPLIFIER (CENTER OF DASH) A/C CONDENSER FAN MOTOR A/C EVAPORATOR TEMPERATURE SENSOR (RIGHT SIDE OF DASH) A/C FUSE (RIGHT SIDE OF DASH) A/C MAGNETIC CLUTCH, LOCK SENSOR A/C SWITCH ACT AIR INLET CONTROL SERVO MOTOR (BEHIND GLOVE BOX, ON A/C- HEATER HOUSING) AIR VENT MODE CONTROL SERVO MOTOR (LEFT SIDE OF DASH) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER RESISTOR (LEFT SIDE OF DASH) BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE CDS FUSE CENTER J/B (BEHIND GLOVE BOX) CENTER J/B (BEHIND RIGHT SIDE OF DASH) DEF DEFOGGER SYSTEM DIODE (A/C) (LEFT KICK PANEL) DRIVER SIDE J/B (LEFT KICK PANEL) ECU-IG FUSE ENGINE CONTROL MODULE (RIGHT SIDE OF DASH) ENGINE ROOM J/B (LEFT FRONT INNER FENDER PANEL) ENGINE ROOM J/B (ON LEFT FRONT INNER FENDER PANEL) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPARTMENT) F/D FOOT B/L FACE HEATER CONTROL SWITCH FAN RELAY 1 FAN RELAY 2 FAN RELAY 3 FRS FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPART- MENT) GRN WIRE GRY WIRE HAC HEATER FUSE HEATER RELAY (RIGHT KICK PANEL) HI OFF LO HOT AT ALL TIMES HOT IN ON OR START HTR FUSE IGN GND INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) LAC LT GRN WIRE LT GRN/RED WIRE MG CLT RELAY MGC SG LOCK MOTOR POSITION SWITCHES OFF LO PNK ACT S-A/C TH L-A/C WIRE PNK WIRE RADIATOR FAN MOTOR RDEF RDI FUSE REC RED WIRE RED/BLU WIRE SA/C SFRS SREC TACH WATER TEMP SWITCH 1 (LEFT SIDE OF ENGINE) WATER TEMPERATURE SWITCH 2 (ON TOP REAR OF INTAKE MANIFOLD) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
