Toyota Avalon XX10 facelift (1997-2000) right rear power window control switch Wiring diagram

AUTO BLK WIRE BLU WIRE DOME FUSE DOOR FUSE DOOR LOCK DOWN DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) ENGINE ROOM J/B (ON LEFT FRONT INNER FENDER PANEL) FRONT LT FRONT RT GAUGE FUSE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START IINSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) INTEGRATION RELAY KEY OFF LEFT FRONT DOOR COURTESY SWITCH LEFT FRONT POWER WINDOW MOTOR LEFT REAR POWER WINDOW CONTROL SWITCH LEFT REAR POWER WINDOW MOTOR NORMAL ORG/ WIRE POWER MAIN RELAY POWER WINDOW MASTER SWITCH PWR FUSE REAR LT REAR RT RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT DOOR COURTESY SWITCH RIGHT FRONT POWER WINDOW CONTROL SWITCH RIGHT FRONT POWER WINDOW MOTOR RIGHT REAR POWER WINDOW CONTROL SWITCH RIGHT REAR POWER WINDOW MOTOR SOLID STATE UP DOWN WHT WIRE WHT/BLK WIRE WINDOW LOCK SW LOCK YEL WIRE
