Toyota Avalon XX10 facelift (1997-2000) pass seat control switch Wiring diagram
This page shows the only wiring diagram for the component.pass seat control switch, which is found in the car Toyota Avalon XX10 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass seat control switch (1 of 1)
AUTO ANTENNA MOTOR AND RELAY
BLK WIRE
BLK/ WHT WIRE
BLOWER SWITCH (MANUAL A/C)
BRN WIRE
COMBINATION METER
DRIVER'S SEAT CONTROL SWITCH
ENGINE ROOM JUNCTION BLOCK (ON LEFT FRONT INNER FENDER PANEL)
FROM
FUEL PUMP
FUEL SENDER
HIGH MOUNTED STOP LIGHT DOOR LOCK CONTROL RECEIVER
I/P JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) NOISE FILTER
LEFT BUCKLE SWITCH (W/O POWER SEAT)
LEFT LICENSE PLATE LIGHT RIGHT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LIGHT
LEFT REAR DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SWITCH
LIGHT FAILURE SENSOR
LUGGAGE COMPARTMENT KEY UNLOCK SWITCH
PASS SEAT CONTROL SWITCH
PASSENGER SEAT HEATER CONTROL SWITCH
POWER SEAT ECU
POWER SEAT MOTOR
POWER SEAT POSITION SENSOR
REAR WINDOW DEFOGGER
RIGHT DOOR LOCK AND UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SWITCH
RIGHT MIRROR HEATER
RIGHT REAR COMBINATION LIGHT
RIGHT REAR DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SWITCH
RIGHT REAR PERSONAL LIGHT
SEAT HEATER (DRIVER SEATBACK) LEFT BUCKLE SWITCH
SEAT HEATER (PASS SEATBACK)
STARTER RELAY
STEREO COMPONENT AMPLIFIER (EXCEPT 4 SPEAKER) RADIO AND PLAYER (W/ 4 SPEAKER)
THEFT DETERRENT ECU
W/ MEMORY W/O MEMORY
W/ POWER SEATS
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (4 of 4) -> PASS SEAT CONTROL SWITCH
