Toyota Avalon XX10 facelift (1997-2000) light control, dimmer switch Wiring diagram
This page shows the only wiring diagram for the component.light control, dimmer switch, which is found in the car Toyota Avalon XX10 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light control, dimmer switch (1 of 1)
BRAKE FLUID LEVEL WARNING SWITCH
CANADA ONLY
DAYTIME RUNNING LIGHT RELAY (MAIN)
DRIVER SIDE JUNCTION BLOCK (UPPER LEFT KICK PANEL)
DRL 3 RELAY
DRL 4 RELAY
FROM IGNITION MAIN RELAY (DIAGRAM 2 OF 4)
FRONT PERSONAL LIGHT
FRONT WIPER/ WASHER SWITCH
HEADLIGHT CLEANER RELAY
IGNITION MAIN RELAY
INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
INTEGRATION RELAY
KEY INTERLOCK SOLENOID
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT FRONT DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
LEFT FRONT SEAT HEATER CONTROL SWITCH
LEFT MIRROR HEATER
LEFT REAR PERSONAL LIGHT
LEFT VANITY LIGHT
LIGHT CONTROL, DIMMER SWITCH
POWER MAIN RELAY
POWER WINDOW MASTER SWITCH
RIGHT VANITY LIGHT
SUB R/B (LEFT FRONT OF ENGINE COMPT)
TO LEFT FRONT SEAT HEATER CONTROL SWITCH (DIAGRAM 2 OF 4)
TRANSPONDER KEY AMPLIFIER
TURN SIGNAL FLASHER RELAY
UNLOCK WARNING SWITCH
WASHER LEVEL WARNING SWITCH
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 4) -> LIGHT CONTROL, DIMMER SWITCH
