Toyota Avalon XX10 facelift (1997-2000) heated oxygen sensor bank 2 sensor 1 Wiring diagram
This page shows the only wiring diagram for the component.heated oxygen sensor bank 2 sensor 1, which is found in the car Toyota Avalon XX10 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heated oxygen sensor bank 2 sensor 1 (1 of 1)
A/F RELAY HEATER
ABS AND TRACTION ACTUATOR
ABS AND TRACTION ECU
ABS ECU, ACTUATOR
BLK WIRE
BRN WIRE
DATA LINK CONNECTOR 1
DATA LINK CONNECTOR 2 COMBINATION METER
EFI RELAY
ENGINE CONTROL MODULE
ENGINE HOOD COURTESY LIGHT SWITCH
ENGINE MAIN RELAY
ENGINE ROOM JUNCTION BLOCK (ON LEFT FRONT INNER FENDER PANEL)
FAN RELAY 2
HEADLIGHT CLEANER MOTOR
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) DATA LINK LINK CONNECTOR 3
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 1
IGNITER
JUNCTION CONNECTOR 1 (LEFT FRONT OF ENGINE COMPT)
JUNCTION CONNECTOR 2 (BEHIND RIGHT CENTER OF DASH)
JUNCTION CONNECTOR 4 (BEHIND RIGHT CENTER OF DASH)
LEFT FOG LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL/ PARKING LIGHT
MOONROOF CONTROL SWITCH
MOONROOF LIMIT SWITCH AND MOTOR MOONROOF CONTROL RELAY
NCA WIRE
NOISE FILTER (FOR IGNITION)
RADIATOR FAN MOTOR
RIGHT FOG LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
TO RIGHT VANITY LIGHT (DIAGRAM 2 OF 4)
W/ ABS
W/ IMMOBLIZER AND/OR TRACTION CONTROL (EXCEPT CALIF)
W/O IMMOBLIZER AND/OR TRACTION CONTROL (EXCEPT CALIF)
WATER TEMPERATURE SWITCH 1
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 4) -> HEATED OXYGEN SENSOR BANK 2 SENSOR 1
