Toyota Avalon XX10 facelift (1997-2000) cty dswl dswh dswd dswp ksw lug Wiring diagram

BLK WIRE BLK/RED WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE CENTER J/B (BEHIND RIGHT SIDE OF DASH) CTY DSWL DSWH DSWD DSWP KSW LUG DASH HARN, BEHIND COMBINATION METER) DOME FUSE DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) ECU-IG FUSE ENGINE ROOM J/B (LEFT FRONT INNER FENDER PANEL) GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HORNS SYSTEM HORN FUSE HOT AT ALL TIMES HOT IN RUN OR START IG LSWD LSWP LSWR TSW IMMOBILIZER CIRUIT (ENGINE CONTROL MODULE) PPL PPL INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) DOOR FUSE INTERGRATION RELAY INTERIOR LIGHT DIODE LEFT FRONT DOOR COURTESY SWITCH LEFT REAR DOOR COURTESY SWITCH LT GRN/BLK WIRE LUGGAGE COMPARTMENT KEY UNLOCK SWITCH ENGINE HOOD COURTESY SWITCH LUGGAGE COMPARTMENT LIGHT SWITCH ORG/ WIRE PPL IND E (GRD) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COURTESY SWITCH RIGHT REAR DOOR COURTESY SWITCH SECURITY INDICATOR LIGHT SH HEAD TAIL HORN THEFT DETERRENT ECU (BEHIND RIGHT SIDE OF DASH) THEFT DETERRENT HORN (ON RIGHT REAR OF ENGINE COMPT) TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE
