Toyota Avalon XX10 facelift (1997-2000) combination meter srs warning indicator Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 PR- PR+ 1 2 3 4 5 6 7 8 9 10 11 12 SFL- SFL+ 11 5 DATA LINK CONNECTOR 1 (RIGHT REAR CORNER OF ENG COMPT) 4 12 DATA LINK CONNECTOR 2 (BEHIND LEFT SIDE OF DASH) AIRBAG SQUIB (FRONT PASSENGER AIRBAG ASSEMBLY) AIRBAG SQUIB (STEERING WHEEL PAD) BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE CENTER J/B (BEHIND RIGHT SIDE OF DASH) CIG/RADIO FUSE COMBINATION METER SRS WARNING INDICATOR DASH BRACE) DATA LINK CONNECTOR 3 (BEHIND LEFT SIDE OF DASH) DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) ESL FSR SSR GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN RUN OR START IGN FUSE INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) SRS FUSE LEFT SIDE AIRBAG SENSOR (LOWER LEFT "B" PILLAR) LEFT SIDE AIRBAG SQUIB LEFT SIDE PRETENSIONER LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT PNK WIRE ORG/ WIRE P+ P- SIL D- D+ PL+ PL- VUPL PNK VUPR WIRE PNK WIRE PNK/BLK WIRE PPL/BLU WIRE RED WIRE RIGHT SIDE AIRBAG SENSOR (LOWER RIGHT "B" PILLAR) RIGHT SIDE AIRBAG SQUIB RIGHT SIDE PRETENSIONER SFR+ SFR- ESR SPIRAL CABLE SSL FSL WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
