Toyota Avalon XX10 facelift (1997-2000) circuit opening relay, data link connector 1 engine control module, Wiring diagram
This page shows the only wiring diagram for the component.circuit opening relay, data link connector 1 engine control module,, which is found in the car Toyota Avalon XX10 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram circuit opening relay, data link connector 1 engine control module, (1 of 1)
A/C AMPLIFIER, POWER SEAT ECU
ABS FUSE FUSE
AIR FUEL RATIO SENSORS, AIR FUEL RATIO HEATER RELAY
ALT FUSE
ALT-S FUSE
AUTO ANTENNA MOTOR AND RELAY, RADIO AND PLAYER, STEREO COMPONENT AMPLIFIER
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN/RED WIRE
CDS FUSE
CIRCUIT OPENING RELAY, DATA LINK CONNECTOR 1 ENGINE CONTROL MODULE,
COIL
COMBINATION SWITCH, FOG LIGHT RELAY, RIGHT LOW BEAM HEADLIGHT
COMPT) CALIF.
DOME FUSE
DRIVER'S SIDE J/B (BEHIND LEFT KICK PANEL)
DRL NUMBER 2 RELAY (CANADA) COIL
DRL NUMBER 3 RELAY, DRL NUMBER 4 RELAY
ECU-B FUSE
EFI FUSE FUSE
EFI RELAY
ENG MAIN RELAY (CAN- ADA) RIGHT HEAD HI
ENGINE ROOM J/B (ON LEFT FRONT OF ENGINE COMPT)
FAN NUMBER 1 RELAY
FOG FUSE HTR FUSE
FOG LIGHTS, FOG LIGHT RELAY
FUSIBLE LINK BLOCK (LEFT FRONT INNER FENDER PANEL)
FUSIBLE LINK BLOCK (LEFT FRONT OF INNER FENDER PANEL)
GENERATOR
GRN WIRE
HEAD RELAY (USA)
IG SW FUSE
LEFT LOW BEAM HEADLIGHT
LT GRN WIRE
MAIN FUSE
MAIN FUSIBLE LINK (12 GA-
MAIN FUSIBLE LINK (18 GA-
NCA WIRE
RAD NUMBER 1 FUSE
RADIATOR FAN MOTOR, FAN NUMBER 1 RELAY
RDI FUSE
RED WIRE
SHORT PIN
STARTER
STARTER RELAY
SUB R/B (CANADA) (ON LEFT FRONT OF ENGINE COMPT) DRL FUSE
SUB R/B (LEFT FRONT OF ENGINE AIR/FUEL HEATER FUSE
TO HORN FUSE (DIAGRAM 2 OF 3)
TO INSTRUMENT PANEL J/B
USA ONLY
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> CIRCUIT OPENING RELAY, DATA LINK CONNECTOR 1 ENGINE CONTROL MODULE,
