Toyota Avalon XX10 facelift (1997-2000) 1 2 3 4 5 6 7 8 9 10 11 12 sflr sflh Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 R+ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 RL- RL+ IND WA TRC- EFI+ 1 2 3 4 5 6 7 8 9 10 11 12 SFLR SFLH 23 22 16 11 WB WA TS TC 4 17 14 TC TRC ABS ABS IND. ABS, TRACTION ACTUATOR (FRONT RIGHT SIDE OF ENGINE COMPARTMENT) ABS, TRACTION ECU (BEHIND RIGHT SIDE OF DASH) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/WHT WIRE CENTER J/B (RIGHT SIDE OF DASH) COMBINATION METER D/G TS MR SRLH SFRR DATA LINK CONNECTOR 1 (RIGHT REAR CORNER OF ENGINE COMPT) DATA LINK CONNECTOR 2 (LEFT SIDE OF DASH) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FL- FL+ FR+ FR- FUSIBLE LINK BLOCK (LEFT FRONT INNER FENDER PANEL) ABS FUSE GAUGE FUSE GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON ECU-IG FUSE HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/C 4 (RIGHT CENTER OF DASH) LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NOISE FILTER RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN (OR RED) WIRE RED/WHT WIRE RED/YEL WIRE RR+ RR- CSW WT TRC+ EFI- NEO STP SHIELD SHIELD SHIELD SLIP IND TRAC OFF IND SRRR SRRH STOP FUSE STOP LIGHT SWITCH TC AST SR SRLR SFRH MT TRACTION CUT SWITCH (LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
