Toyota Avalon XX10 (1994-1997) left key lock and unlock switch wiring diagram
This page shows the only wiring diagram for the component.left key lock and unlock switch, which is found in the car Toyota Avalon XX10 (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left key lock and unlock switch wiring diagram (1 of 1)
BLK WIRE
BLU/ORG WIRE
BR BR AR BR AR
CENTER J/B (BEHIND GLOVE BOX)
CIG/RADIO FUSE
FRONT PERSONAL LIGHT (W/ MOON ROOF)
FRONT PERSONAL LIGHT (W/O MOON ROOF XLS GRADE)
GAUGE FUSE
GRN/RED WIRE
HOT AT ALL TIMES ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMP) DOME FUSE
HOT IN ACC OR ON
HOT IN ON OR START
IGNITION KEY CYLINDER LIGHT
INSTRIMENT PANEL J/B (LEFT SIDE OF DASH)
INTEGRATION RELAY
INTERIOR LIGHT (W/O MOONROOF XL GRADE)
LEFT FRONT DOOR COURTESY LIGHT
LEFT FRONT DOOR COURTESY SWITCH
LEFT FRONT DOOR UNLOCK DETECTION SWITCH (USA XLS GRADE AND CANADA)
LEFT KEY LOCK AND UNLOCK SWITCH
LEFT REAR DOOR COURTESY SWITCH
LEFT REAR DOOR UNLOCK DETECTION SWITCH
LEFT REAR PERSONAL LIGHT (XLS GRADE)
LEFT VANITY LIGHT
LT GRN/BLK WIRE
LUGGAGE COMP LIGHT
LUGGAGE COMP. LIGHT SWITCH
NOISE FILTER (XLS GRADE)
OFF
OFF DOOR
ON DOOR
OPEN DOOR WARNING LIGHT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR COURTESY LIGHT
RIGHT FRONT DOOR COURTESY SWITCH
RIGHT FRONT DOOR UNLOCK DETECTION SWITCH
RIGHT REAR DOOR COURTESY SWITCH
RIGHT REAR DOOR UNLOCK DETECTION SWITCH
RIGHT REAR PERSONAL LIGHT (XLS GRADE)
RIGHT VANITY LIGHT
USA XLS GRADE AND CANADA
USA XLS GRADE AND CANADA USA XL GRADE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit -> LEFT KEY LOCK AND UNLOCK SWITCH
