Toyota Avalon XX10 (1994-1997) floor shift Wiring diagram

+B STP 12 8 3 B+ 1996 ONLY A/C SWITCH (CENTER OF DASH) A/T DIODE (COLUMN SHIFT) (RIGHT SIDE OF DASH) BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE CIGAR FUSE COLUMN SHIFT COLUMN SHIFT FLOOR SHIFT CRUISE CONTROL MODULE (RIGHT SIDE OF DASH) DATALINK CONNECTOR 1 (RIGHT REAR OF ENGINE COMPT) EFI FUSE EFI RELAY ELECTRONIC CONTROLLED TRANSMISSION SOLENOID ENGINE CONTROL MODULE (RIGHT SIDE OF DASH) ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE) ENGINE ROOM J/B (LEFT FRONT OF ENGINE COMPT) FLOOR SHIFT GAUGE FUSE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HOT IN ON OR ACC HOT IN ON OR START IDL INSTRUMENT CLUSTER INSTRUMENT CLUSTER (SPEEDOMETER) INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) IGN FUSE J/B 1 (LEFT SIDE OF DASH) J/B 3 (BEHIND GLOVE BOX) L INDIC 2 INDIC D INDIC N INDIC R INDIC P INDIC LEFT FRONT FENDER) LT GRN WIRE NO. 3 NO. 1 NO. 2 NO. 4 O/D DIRECT CLUTCH SPEED SENSOR (FRONT OF TRANS) O/D MAIN SWITCH (FLR SHFT- BELOW CTR CONSOLE) (DASH SHFT- CENTER OF DASH) O/D OFF INDIC ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (FRONT OF TRANSMISSION) PNK WIRE PNK/BLU WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE SLN- STARTER FUSE STARTING/ CHARGING STOP FUSE STOP- LIGHT SWITCH (ABOVE BRAKE PEDAL) THROTTLE POSITION SENSOR (ON THROTTLE BODY) VEHICLE SPEED SENSOR (FRONT OF TRANS) VIO WIRE VIO/YEL WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE
