Toyota Avalon XX10 (1994-1997) daytime running light relay 2 Wiring diagram

1 2 3 IG AUTOMATIC LIGHT CONTROL SENSOR (UPPER LEFT SIDE OF DASH) BC CENTER J/B (BEHIND GLOVE BOX) BLK WIRE BR AR AS CENTER J/B (BEHIND GLOVE BOX) COMBINATION METER COMBINATION SWITCH CTY 4 5 6 DAYTIME RUNNING LIGHT RELAY 2 DIMMER SWITCH DOME FUSE DRIVER'S SIDE J/B (LEFT KICK PANEL) DRL FUSE DRL RELAY 3 DRL RELAY 4 ENGINE J/B (FRONT OF LEFT FENDER) FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) GAUGE FUSE GRN/ORG WIRE GRN/RED WIRE HEAD HEAD OFF TAIL HEAD- LIGHT RELAY HIGH BEAM IND HOT AT ALL TIMES HOT IN ON OR START I/P J/B (LEFT SIDE OF I/P) INSTRUMENT CLUSTER SYSTEM INTEGRATION RELAY (LEFT SIDE OF DASH) LEFT FRONT DOOR COURTESY SWITCH LEFT HIGH HEAD- LIGHT LEFT LOW HEAD- LIGHT LEFT RIGHT HIGH HEAD FUSE HIGH HEAD FUSE LEFT RIGHT LOW HEAD FUSE LOW HEAD FUSE LIGHT CONTROL SWITCH MAIN DAYTIME RUNNING LIGHT RELAY (LEFT SIDE OF I/P) MAIN FUSE OFF PARKING BRAKE SWITCH (UPPER LEFT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT HIGH HEAD- LIGHT RIGHT LOW HEAD- LIGHT STARTING/ CHARGING SYSTEM SUB R/B (NEAR BATTERY) TAIL WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE
