Toyota Aurion II (2012-2017) child security lock disable relay Wiring diagram
This page shows the only wiring diagram for the component.child security lock disable relay, which is found in the car Toyota Aurion II (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram child security lock disable relay (1 of 1)
AJAR SW SIG
BLK WIRE
BRN/LT GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHILD SECURITY LOCK DISABLE RELAY
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DRIVER DOOR LOCK SWITCH
EXTENDED CAB CREW CAB
GRY WIRE
GRY/BLK WIRE
GRY/LT GRN WIRE
GRY/WHT WIRE
LIN BUS 3
LIN BUS 4
LOGIC
LT GRN/GRY WIRE
LT GRN/YEL WIRE
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER WINDOW SWITCH
RF DR
RIGHT REAR DOOR LATCH ASSEMBLY (CREW CAB)
RIGHT REAR WINDOW SWITCH
RR DR -
VIO/YEL WIRE
W/ REMOTE KEYLESS ENTRY
W/O REMOTE KEYLESS ENTRY
WHT/LT BLU WIRE
YEL WIRE
YEL/LT GRN WIRE
Go to component -> Power door locks circuit (2 of 3) -> CHILD SECURITY LOCK DISABLE RELAY
