Electrochromic mirror circuit, with rear view camera for Toyota 4Runner V (2009-2013)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 IG 1 2 4 3 CV- CV+ CB+ CGND BLK WIRE BLU WIRE BRN WIRE CGKD CB+ CV- CV+ DRIVER SIDE R/B ASSEMBLY (LEFT END OF DASH) ECU- IG 1 FUSE ECU-IG 2 FUSE GRN WIRE INNER REAR VIEW MIRROR ASSEMBLY J/B 4 (LEFT SIDE OF DASH) J/B 5 (CENTER OF DASH) NCA WIRE PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) REAR TELEVISION CAMERA ASSEMBLY (CENTER OF TAILGATE) RED WIRE RELAY ENERGIZED REV WHT WIRE WHT/BLK WIRE
