Electronic power steering circuit for Toyota 4Runner V (2009-2013)

1 2 3 4 5 6 7 8 CANH CANL GND BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DRIVER SIDE J/B ECU- IG 1 FUSE ECU-B FUSE ENGINE ROOM R/B ASSEMBLY (LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN WIRE HOT AT ALL TIMES HOT IN ON OR START J/B 4 (LEFT SIDE OF DASH) J/B 5 (CENTER OF DASH) LT GRN WIRE MGND POWER STEERING ECU ASSEMBLY (CENTER OF DASH) POWER STEERING IND RED WIRE SOF+ SOF- SOLENOID VALVE ASSEMBLY (RIGHT FRONT OF ENGINE) STEERING SENSOR (LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE
