Toyota 4Runner IV facelift (2005-2009) Shift interlock circuit

1 2 3 4 5 6 7 8 9 10 11 12 IG BLK/RED WIRE BLU/WHT WIRE CE CENTER J/B (BEHIND RIGHT CENTER OF DASH) DRIVER SIDE J/B (BEHIND LOWER LEFT END ECU-IG FUSE ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) FB CENTER J/B (BEHIND RIGHT CENTER OF DASH) FUSE GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START J/C 12 (BEHIND INSTRUMENT CLUSTER) J/C 20 (BEHIND INSTRUMENT CLUSTER) J/C 37 (BEHIND RIGHT KICK PANEL) J/C 4 (BEHIND UPPER LEFT END OF DASH) J/C 5 (BEHIND RIGHT KICK PANEL) KEY INTERLOCK SOLENOID (LEFT SIDE OF DASH) KLS+ OF DASH) PNK WIRE SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE, NEAR SHIFT LEVER ASSEMBLY) STOP FUSE STOPLIGHT SWITCH (BEHIND LEFT SIDE OF DASH, ABOVE BRAKE PEDAL) WHT WIRE WHT/BLK WIRE
