4.7l, 4wd circuit for Toyota 4Runner IV (2002-2005)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 GND BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CENTER DIFF LOCK CENTER J/B (BEHIND RIGHT CENTER OF DASH) COMBINATION METER CONTROL SWITCH DIFFERENTIAL LOCK SWITCH DOME FUSE DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT END OF DASH) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE GAUGE FUSE GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START II (BEHIND RIGHT CENTER OF DASH) IK J/C 37 (BEHIND RIGHT KICK PANEL) J/C 10, J/C 11 (BEHIND INSTRUMENT CLUSTER) J/C 14, J/C 15 (BEHIND INSTRUMENT CLUSTER) J/C 20 (BEHIND INSTRUMENT CLUSTER) J/C 24 J/C 25 (BEHIND RIGHT CENTER OF DASH) J/C 28 (BEHIND RIGHT SIDE OF DASH) J/C 29, J/C 30 (BEHIND RIGHT END OF DASH) J/C 31, J/C 32 (BEHIND RIGHT END OF DASH) J/C 33, J/C 34 (BEHIND RIGHT END OF DASH) J/C 7 (BEHIND LEFT END OF DASH) J/C 8, J/C 9 (BEHIND INSTRUMENT CLUSTER) LO DL PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) RED WIRE RED/BLK WIRE RED/BLU WIRE SKID CONTROL ECU (BEHIND LEFT END OF DASH) SPEEDO TRANSFER SHIFT ACTUATOR (ON TRANS- MISSION) VIO WIRE VIO/RED WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/RED WIRE
