Toyota 4Runner III (1995-2003) passengers power seat control switch Wiring diagram
This page shows the only wiring diagram for the component.passengers power seat control switch, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passengers power seat control switch (1 of 1)
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CENTER J/B (BEHIND LEFT SIDE OF DASH, TO RIGHT OF STEERING COLUMN)
DRIVER SIDE J/B (LEFT SIDE OF DASH)
FRONT
HOT AT ALL TIMES
J/C 9 (BEHIND RIGHT SIDE OF DASH)
PASSENGER'S SEAT RECLINING CONTROL MOTOR
PASSENGER'S SEAT SLIDE CONTROL MOTOR
PASSENGERS POWER SEAT CONTROL SWITCH
POWER FUSE
REAR
RECLINING
SLIDE
WHT/BLK WIRE
Go to component -> Passenger power seat circuit -> PASSENGERS POWER SEAT CONTROL SWITCH
